Introduction:
The Jacketed V Type Ball Valve is a specialized product designed to meet the needs of industries that require precise control over their fluid handling operations. This type of valve is particularly ideal for high temperature and high-pressure applications since it is designed to withstand extreme conditions. At our manufacturing facility in China, we have created a cutting-edge technology that derives high-quality Jacketed V Type Ball Valves that deliver superior performance, durability, and effective results.
Features and Benefits:
Our Jacketed V Type Ball Valve is made from high-grade materials that are carefully selected to withstand extreme pressure, temperature and corrosive environments. Our valves are designed with a precision ball that ensures smooth operation and precise control of the flow of fluid. The Jacketed V Type Ball Valve has a unique design that makes it extremely efficient in maintaining both the temperature and the consistency of the fluid it is handling. This feature ensures that any fluid it handles is kept at the optimal temperature for its subsequent use.
Another unique feature of our Jacketed V Type Ball Valve is its full jacket coverage. This feature makes it ideal for handling materials that require low-temperature fluids to maintain their characteristics. Additionally, having a full-jacket coverage also prevents the quick cooling and a sudden change in temperature of the fluid. This feature helps to prevent damage to the equipment or products the fluid is used for.
The Jacketed V Type Ball Valve is also designed for easy installation and maintenance. Its smooth body design ensures that it is easy to clean and maintain while also reducing the risk of contamination from unwanted dirt and debris. Our Jacketed V Type Ball Valve also features a simple design that makes it easy to replace or repair any parts that might require service over time.
Applications for the Jacketed V Type Ball Valve:
Our Jacketed V Type Ball Valve is ideal for a wide range of industries that require precise control of their fluid handling operations. The industries that can benefit from our product include chemical manufacturing, pharmaceuticals, food and beverage industries, and oil and gas industries. The Jacketed V Type Ball Valve is also well-suited for processes that require a uniform flow rate such as in steam pipes, heating systems and other fluid handling processes.
Conclusion:
Our Jacketed V Type Ball Valve is the ideal choice for industries that require precise control over their fluid handling operations. Our cutting-edge manufacturing technology delivers superior quality valves that are designed to withstand extreme conditions and provide excellent performance, durability, and ease of maintenance. If you are interested in purchasing our Jacketed V Type Ball Valve, feel free to contact us today, and we will be happy to provide you with more information and answer any questions that you might have.
Introduction
The jacketed V type ball valve has a shearing effect on the valve seat due to the V-shaped structure of the ball core. Therefore, it is suitable for the control of relevant process parameters in the suspension medium containing fibers or tiny solid particles in papermaking, chemical, metallurgical and other industrial enterprises, especially for pulp, white water, black liquor, automatic adjustment of the fluid of suspended particles such as white liquor and the fluid medium of thick and turbid slurry.
Features
The jacketed V type ball valve has an elastic load pressure auxiliary sealing seat to ensure the tight contact between the valve seat and the ball core. It has a one-piece body structure, and there is no possibility of potential leakage. It also has equal percentage characteristics, a wide control range and a particularly stable control process, and can be widely used in a variety of technological processes. The valve stem and the ball core are connected by involute splines. When the tooth profile is loaded, the radial force on the teeth can play the role of automatic centering, and the force of each tooth is uniform, so that it has high strength and long service life.
Details
| Size Range: | DN 25~250mm NPS 1”-10” (Wafer) DN 25~500mm NPS 1”-20” (Flange) |
| Press. Rate： | PN 10/16/25/40/63 ANSI 150/300/600 |
| Temp. Range： | Metal Seat -29...+450℃ Resilient Seat -29...+150℃ |
| Seal Tightness： | Metal Seat Class IV Resilient Seat Class VI |
